产品优势
图本PE-HDXb阻氧管道由高密度交联聚乙烯与EVOH共挤制成,SI-O-SI三维网状结构提供其额外的耐热性,使其管材提升耐环境应力开裂性能;阻氧技术保证其管材在较低的相对湿度环境中,依然保持其良好的阻隔性能;螯合技术使其管材与铜、铁等管件连接处,充分降低其塑性材质的老化粘性,有效延长系统使用寿命。
本产品执行ISO15875与ISO17455标准,采用ClassA设计标准,适用Class5环境条件下的高温采暖系统运行; 本产品应用行业领域:给排水、供暖、空调等领域; 本产品适配连接方式:滑紧、快插、卡套。
基本参数
ISO15875标准PE-HDXb型聚乙烯管,具有更高的耐热性,优质PE-HD基料,EVOH阻氧层,符合DIN4726/ISO17455,耐变形和外部影响,耐应力开裂。
工作温度: <75°C
最高温度: 95°C
工作压力: 10bar
符合ISO10508标准Class5级所有要求
最小弯曲半径:5xd[d=外径]
安装温度:-5°C至+30°C
生产标准
标准成就品质
High Standard achievement quality
ISO15875 Plastics piping systems for hot and cold
water installations — Crosslinked
polyethylene [PE-X]
ISO17455 Plastics piping systems-Multilayer
pipes-Determination of the oxygen
permeability of the barrier pipe
ISO10508 Plastics piping systems for hot and
cold water installations -guidance
for classification and design
ISO4065 Thermoplastics pipes-Universal
wall thickness table
ISO1746 Rubber or plastics hoses
and tubing-Bending tests
ISO4672 Rubber and plastics
hoses-Sub-ambient temperature
flexibility tests
ISO1167 Thermoplastics pipes,
fittings and assemblies for the
conveyance of fluids-Determination
of the resistance to internal pressure
DIN4726 Warm water surface heating
systems and radiator connecting
systems-Plastics piping systems and multilayer piping systems
